Lilliput A11 10.1 Inch Full HD Pro SDI Broadcast Monitor With 4K Support
₹27,990.00
-
Panel Type
LCD
-
Display Size
10.1″ / 25.7 cm
-
Aspect Ratio
16:10
-
Viewing Angle
Horizontal: 175° Vertical: 175°
-
Touchscreen
No
-
Maximum Brightness
320 cd/m2
-
Contrast Ratio
1000:1
-
Bit Depth / Color Support
8-Bit (16.7 Million Colors)
-
Pixels Per Inch (ppi)
224 ppi
-
Image Controls
Check Field, Color Temperature Selection, Customizable Aspect Ratios, False Color, Focus Peaking, Histogram, Image Flip, Underscan, Zebra
-
Wi-Fi
None
-
Video
1 x HDMI Type A (HDMI 1.4b) Input 1 x BNC (3G-SDI) Input 1 x DE-15/DB-15 (VGA) Input 1 x HDMI Type A (HDMI 1.4b) Output 1 x BNC (3G-SDI) Loop Output
-
Embedded Audio
HDMI SDI
-
Audio
1 x 1/8″ / 3.5 mm Headphone Output
-
Built-In Speaker
1
-
Power
1 x Barrel (24 VDC) Input
-
Other I/O
1 x USB 2.0 (USB Type-B)
-
Card Slot
None
-
Video Format
HDMI UHD 4K: 30 1080p: 30 1080i: 30 720p: 30 576p: 30 576i: 30 480p: 30 480i: 30
-
Battery Type
1 x L-Series (Interchangeable Mount)
-
Power Consumption
13 W
-
Mounting-Hole Pattern
75 x 75 mm
-
Mounting
1 x 1/4″-20 Female
-
Operating Temperature
32 to 122°F / 0 to 50°C
-
Storage Temperature
-4 to 140°F / -20 to 60°C
-
Dimensions
9.9 x 6.2 x 1″ / 252 x 157 x 25 mm
-
Weight
550 g
-
Warranty Length
Limited 1-Year Warranty
-
Package Weight
1628
-
Box Dimensions (LxWxH)
10.8 x 7.1 x 4.5″
Availability: In Stock
Compare
Details
Crisp 10.1″ Display :-
- 10.1″ LCD panel
- 320 cd/m² brightness
- 1000:1 contrast
- Rich 8-bit color
- 175° horizontal and vertical viewing angle
3G-SDI & 4K HDMI Input/output :-
- 4K30 HDMI input/output
- 3G-SDI input/output
- VGA input
Tools :-
- Two user-assignable buttons
- Focus peaking
- Selectable aspect ratios
- Exposure control
- False color function
- Histogram
- Zoom function
- Audio meter
Power & Mounting :-
- Includes one Sony L-series type battery plate
- Can be used with separate V-mount or Gold mount plates
- 75 x 75mm VESA mounting pattern
- 1/4″-20 mounting thread
- 7 to 24V DC input range
